Druckpunkttaster

KSC PF Serien
Abgedichteter Taktschalter für SMT

Tactile KSC PF product image

Die Abbildung zeigt die Produktserie und stellt möglicherweise nicht die tatsächliche Teilenummer dar

img description

Toolbox

img description

Downloads

Technischen Support kontaktieren

Händlerbestand prüfen

Muster anfordern

Die KSC PF-Serie ist eine einzigartige Kombination aus einem kompakten Kurzhubtaster zur Oberflächenmontage mit einem kompakten Formfaktor (6,2 x 6,2 x 5,2 mm) und dem vergussfreundlichen verlängerten Käfig, der perfekt für medizinische, Automobil- und Industrieanwendungen geeignet ist.

Eigenschaften und Vorteile

Extended Cage for easy potting
IP67
Soft actuator 5,2mm high

Typische Anwendungsbereiche

Automotive openings
Electrosurgical Tools

Technische Daten

Dielectric Strength:
> 250 Vrms
Electrical Life:
Between 300,000 and 1,000,000 cycles depending on model
Insulation Resistance:
> 10 megohms
Operating Temperature:
-40°C to 85°C
Solderability:
Lead free reflow soldering process according with IEC61760-1
Contact Rating:
50mA
Contact Resistance:
< 100 milliohms

Most Common

Current Rating

Circuit Group

Circuit

Mounting Type Group

Mounting Type

Sealing

Illumination

Switch Function

Electrical Life Cycles

Actuator Type

Actuator Height off PCB, from Pins

Actuator Orientation

Termination Style

Footprint

Illumination Voltage (Nominal)

Illumination Type, Color

Operating Force

Additional Features

Packaging

Alle zurücksetzen

= Am häufigsten verwendet

1
of
1

Ausgewählte Teile vergleichen

Part Number
KSC421G 70SH LFS PF 3D-Modell \| Technischen Support kontaktieren \| Bestand prüfen Muster anfordern
KSC421J 70SH LFS PF 3D-Modell \| Technischen Support kontaktieren \| Bestand prüfen Muster anfordern
KSC422G 70SH LFS PF 3D-Modell \| Technischen Support kontaktieren \| Bestand prüfen Muster anfordern
KSC422J 70SH LFS PF 3D-Modell \| Technischen Support kontaktieren \| Bestand prüfen Muster anfordern
KSC441G 70SH LFS PF 3D-Modell \| Technischen Support kontaktieren \| Bestand prüfen Muster anfordern
KSC441J 70SH LFS PF 3D-Modell \| Technischen Support kontaktieren \| Bestand prüfen Muster anfordern
KSC442G 70SH LFS PF 3D-Modell \| Technischen Support kontaktieren \| Bestand prüfen Muster anfordern
KSC442J 70SH LFS PF 3D-Modell \| Technischen Support kontaktieren \| Bestand prüfen Muster anfordern
KSC461G 70SH LFS PF 3D-Modell \| Technischen Support kontaktieren \| Bestand prüfen Muster anfordern
KSC461J 70SH LFS PF 3D-Modell \| Technischen Support kontaktieren \| Bestand prüfen Muster anfordern
KSC471G 70SH LFS PF 3D-Modell \| Technischen Support kontaktieren \| Bestand prüfen Muster anfordern
KSC471J 70SH LFS PF 3D-Modell \| Technischen Support kontaktieren \| Bestand prüfen Muster anfordern

Current Rating	Circuit	Mounting Type	Sealing	Illumination	Switch Function	Electrical Life Cycles	Actuator Type	Actuator Height off PCB, from Pins	Actuator Orientation	Termination Style	Footprint	Illumination Voltage (Nominal)	Illumination Type, Color	Operating Force	Additional Features	Packaging
50mA @ 32VDC	SPST-NO	Surface Mount	Sealed - IP67	No/None	Off-Mom	300.000	Standard	5.20mm	Top Actuated	Gull Wing	6.20mm x 6.20mm			170gf		Tape & Reel
50mA @ 32VDC	SPST-NO	Surface Mount	Sealed - IP67	No/None	Off-Mom	300.000	Standard	5.20mm	Top Actuated	J Lead	6.20mm x 6.20mm			170gf		Tape & Reel
50mA @ 32VDC	SPST-NO	Surface Mount	Sealed - IP67	No/None	Off-Mom	1.000.000	Standard	5.20mm	Top Actuated	Gull Wing	6.20mm x 6.20mm			170gf		Tape & Reel
50mA @ 32VDC	SPST-NO	Surface Mount	Sealed - IP67	No/None	Off-Mom	1.000.000	Standard	5.20mm	Top Actuated	J Lead	6.20mm x 6.20mm			170gf		Tape & Reel
50mA @ 32VDC	SPST-NO	Surface Mount	Sealed - IP67	No/None	Off-Mom	300.000	Standard	5.20mm	Top Actuated	Gull Wing	6.20mm x 6.20mm			400gf		Tape & Reel
50mA @ 32VDC	SPST-NO	Surface Mount	Sealed - IP67	No/None	Off-Mom	300.000	Standard	5.20mm	Top Actuated	J Lead	6.20mm x 6.20mm			400gf		Tape & Reel
50mA @ 32VDC	SPST-NO	Surface Mount	Sealed - IP67	No/None	Off-Mom	1.000.000	Standard	5.20mm	Top Actuated	Gull Wing	6.20mm x 6.20mm			400gf		Tape & Reel
50mA @ 32VDC	SPST-NO	Surface Mount	Sealed - IP67	No/None	Off-Mom	1.000.000	Standard	5.20mm	Top Actuated	J Lead	6.20mm x 6.20mm			400gf		Tape & Reel
50mA @ 32VDC	SPST-NO	Surface Mount	Sealed - IP67	No/None	Off-Mom	300.000	Standard	5.20mm	Top Actuated	Gull Wing	6.20mm x 6.20mm			625gf		Tape & Reel
50mA @ 32VDC	SPST-NO	Surface Mount	Sealed - IP67	No/None	Off-Mom	300.000	Standard	5.20mm	Top Actuated	J Lead	6.20mm x 6.20mm			625gf		Tape & Reel
50mA @ 32VDC	SPST-NO	Surface Mount	Sealed - IP67	No/None	Off-Mom	300.000	Standard	5.20mm	Top Actuated	Gull Wing	6.20mm x 6.20mm			400gf		Tape & Reel
50mA @ 32VDC	SPST-NO	Surface Mount	Sealed - IP67	No/None	Off-Mom	300.000	Standard	5.20mm	Top Actuated	J Lead	6.20mm x 6.20mm			400gf		Tape & Reel
